Improve PySpark json reads with explicit schema

Improve your PySpark ETL's performance by providing explicit schema

Have you ever stumbled upon a Spark ETL and you were left wondering how a simple loading of a dataset can take hours, even though the filtered dataset you are specifying is relatively small? While there can be multiple reasons for the ETL being slow, from the cloud provider to wrong cluster Spark configuration of executors, we will focus in this blogpost on optimizing dataframe reads for json and csv datasets.

Going through the Spark Scala source code we can already understand one of the reasons of our query being slow. When reading json datasets Spark will go through all the json files once to infer the schema before loading our datasets. In case of a heavily distributed dataset across multiple json files, this can be a source of considerable time spent by Spark Executors. We can reference the Spark Documentation in order to better understand what kind of properties are set by default when reading json datasets. A quick fix to speed our query is to set a smaller sampling ratio for Spark schema inference, by default this value is set to 1.0. A better long term fix for your ETL code, especially if the data infrastructure provides some schema guarantees, is to provide Spark Schema when reading your datasets.

How to provide a Spark schema when querying json files

#1 Provide a typed PySpark Schema

As an example we will use an order event that we might receive via our event-bus. This event will have some custom metadata as well as the order itself with custom order items. In this case our PySpark schema would look like this:

from pyspark.sql.types import *

schema = StructType([
                StructField("metadata",StringType(),False),
                StructField("order",
                            StructType([
                                StructField("order_id",StringType(),False),
                                StructField("created_at",TimestampType(),True),
                                StructField("updated_at",TimestampType(),True),
                                StructField("customer_id",StringType(),False),
                                StructField("order_items",
                                            ArrayType(
                                                StructType([
                                                    StructField("item_id",StringType(),False),
                                                    StructField("item_value",DoubleType(),False)]),False),False)]),False)])

We would read the dataframe with the following PySpark command:

df = spark.read.json("our/path", schema=schema)

With this configuration spark will read the dataset directly without trying to infer the schema. This setup can feel quite cumbersome as the data engineer needs to work with Spark types directly, and the definition of the struct can be quite verbose.

#2 Provide PySpark schema as Python dataclasses

We can improve the example above using the library tinsel that we have leveraged in previous blogposts. To install the library in your notebook simply run: %pip install tinsel Using tinsel transformer we can write our schema as dataclasses as in the following example:

from typing import List, NamedTuple, Optional
from tinsel import struct, transform

@struct
class OrderItem(NamedTuple):
  item_id: str
  item_value: float

@struct
class Order(NamedTuple):
  order_id: str
  created_at: Optional[datetime]
  updated_at: Optional[datetime]
  customer_id: str
  order_items: List[OrderItem]

@struct
class Event(NamedTuple):
    metadata: str
    order: Order

schema = transform(Event)
df = spark.read.json("our/path", schema=schema)

#3 Save and load json schema for PySpark dataframes

Writing our schema as python dataclasses is already an excellent step forward, however this might not always be the right solution. Maintaining schema and schema migration can be quite challenging, and the software developers might opt on using version control to specify the schemas as yaml or json. With PySpark we can load the schema specified as json as a static resource, for example from S3. Using the example above we can generate the json schema:

df.schema.json()

Which would print our schema:

json_schema =
"""
    {
  "fields": [
    {
      "metadata": {},
      "name": "metadata",
      "nullable": false,
      "type": "string"
    },
    {
      "metadata": {},
      "name": "order",
      "nullable": false,
      "type": {
        "fields": [
          {
            "metadata": {},
            "name": "order_id",
            "nullable": false,
            "type": "string"
          },
          {
            "metadata": {},
            "name": "created_at",
            "nullable": true,
            "type": "timestamp"
          },
          {
            "metadata": {},
            "name": "updated_at",
            "nullable": true,
            "type": "timestamp"
          },
          {
            "metadata": {},
            "name": "customer_id",
            "nullable": false,
            "type": "string"
          },
          {
            "metadata": {},
            "name": "order_items",
            "nullable": false,
            "type": {
              "containsNull": false,
              "elementType": {
                "fields": [
                  {
                    "metadata": {},
                    "name": "item_id",
                    "nullable": false,
                    "type": "string"
                  },
                  {
                    "metadata": {},
                    "name": "item_value",
                    "nullable": false,
                    "type": "double"
                  }
                ],
                "type": "struct"
              },
              "type": "array"
            }
          }
        ],
        "type": "struct"
      }
    }
  ],
  "type": "struct"
}"""

The schema can now be loaded using the following command:

import json

new_schema = StructType.fromJson(json.loads(json_schema))
df = spark.read.json("our/path", schema=new_schema)
